Máy đo lực vặn nắp chai tự động ADATMV5 S AT2E Việt Nam

Description:

Technical specifications Complies with CFR21- FDA standards

• Autonomous torque control module
• Integrable regulatory weighing (option)
• Built-in bubble point leak tester (option)
• Use with ultra simplified touch interface
• Measure in screwing and unscrewing.
• Measurement range: from 00.00 to 99.99Kgf.cm
• 6 cycles: Tightening torque - opening / angular positioning + torque / breaking / unblocking breaking overshooting failure / non-destructive testing  / weighing / bubble point leak test
• Choice of unit: Kgf.cm / Inch.lbs / daN.cm / N.cm / Nm
• Adjustable rotation speeds (1,2)
• Graphic of the test
• 0.5% PE precision
• 30 products that can be memorized
• 10 groups of thresholds: low; above; with bar-graph
• 10 memorizable operators
• Memorization of 9999 measurements
• Configuration by administrator code, the operator with access to the choices only
• Language: English, French, Spanish other on request
• Supplied with COFRAC ASTM UKAS, DKD NIST ENAC calibration certificate
• 110 / 220V 50-60 Hz

 Automated part:

• Opening front doors with secure door contact
• Automatic reset during cycle start
• Automatic pre-adjustment of the column position
• Simple programming
• Adjusting the screwing / unscrewing speed
• Adjustment of couples validation angles
• Autonomous mode (automatic start)
• Tests by number of screw heads or filling valve numbers

Mechanical part:

• INOX and transparent plexi set
• Choice of the type of jaw (body or under bottle neck)
• dimensions: 1090 (W) x 710 (W) x 1120 (H) mm
• Weight: 120 Kg

​
