Chi tiết sản phẩm

  • Đồng hồ áp suất P252 series Wise Control

  • Mã SP:
  • Giá : Liên hệ
  • P252 series are suitable for a corrosive environment. Typical application includes: Chemical, petro-chemical, refining process, power generation, marine and foods industry. Its stainless case and cover have a good appearance and the excellent proof against corrosive and chemical attack.

Nominal diameter 63, 80, 100 and 160 mm
Accuracy P2522 (63 mm) and P2523 (80 mm) : ±1.6 % of full scale
P2524 (100 mm) and P2526 (160 mm) : ±0.5 % of full scale
±1.0 % of full scale
Scale range (MPa, kPa, bar) 63 and 80 mm : -0.1 ~ 0 to 0 ~ 100 MPa
100 and 160 mm : -0.1 ~ 0 to 0 ~ 200 MPa
Working pressure Steady : 75 % of full scale (63 and 80 mm)
             100 % of full scale (100 and 160 mm)
Over range protection : 130 % of full scale
Working temperature Ambient : -40 ~ 65 ℃
Fluid : Max. 200 ℃
Degree of protection EN60529/IEC529/IP65
Temperature effect Accuracy at temperature above and below the reference temperature (20 ℃) will be effected by approximately
±0.4 % per 10 ℃ of full scale


Standard features

Pressure connection Stainless steel (316SS)
Element Stainless steel (316SS),
Model : P2524 (100 mm) and P2526 (160 mm)
<10 MPa : C type bourdon tube
≥10 MPa : Helical type bourdon tube
Model : P2522 (63 mm) and P2523 (80 mm)
<6 MPa : C type bourdon tube
≥6 MPa : Helical type bourdon tube
Blowout protection Back, Rubber disc for 80, 100 and 160 mm
Top, Rubber disc for 63 mm
Case Stainless steel (304SS)
Cover Stainless steel (304SS)
Bayonet type
Window Laminated safety glass
Movement Stainless steel
Dial White aluminium with black graduations
Pointer Black painted aluminium alloy
Process connection 63 mm : ⅛", ¼" PT, NPT and PF
80 mm : ¼", ⅜" PT, NPT and PF
100 and 160 mm : ¼", ⅜", ½" PT, NPT and PF
Certificates Pressure equipment directive (2014/68/EU) Annex III Module H
ATEX Ex II GD c IIc TX
Option Zero adjustable pointer
(Only available with diameter 100 and 160 mm)
Zero adjustment (External) : 100 and 160 mm
Pressure connection and element : Monel
(Only available with diameter 100 and 160 mm)
